1>. Available Diameter, Type & Packing
| Size (mm) | Dia 0.5 | Dia 0.8 | Dia 1.0 | Dia 1.2 | Dia 1.6 | Dia 2.0 | Dia 2.4 | Dia 2.5 | Dia 3.0 | Dia 3.2 | Dia 4.0 | Dia 4.8 | Dia 5.0 |
| Size (inch) | 0.020' | 0.031" | 0.039" | 0.047" | 0.062" | 0.079" | 0.093" | 0.098' | 0.12" | 0.125" | 0.16' | 0.19' | 0.20' |
| Straight | OK | OK | OK | OK | OK | OK | OK | OK | OK | ||||
| Spool | OK | OK | OK | OK | OK | ||||||||
| Coil | OK | OK | OK | OK | OK | OK | OK | OK | OK |
grade | Tensile strength(min) | Yeild strength(min) | Elongation(%) | ||
ksi | MPa | ksi | MPa | ||
1 | 35 | 240 | 20 | 138 | 24 |
2 | 50 | 345 | 40 | 275 | 20 |
3 | 65 | 450 | 55 | 380 | 18 |
5 | 130 | 895 | 120 | 828 | 10 |
7 | 50 | 345 | 40 | 275 | 20 |
9 | 90 | 620 | 70 | 438 | 15 |
12 | 70 | 438 | 50 | 345 | 18 |
Product Names | Dimensions(mm) | Grade | Standards |
Titanium wire | Φ(0.06~7.0)ÃL | GR1,GR2 | ASTM B863 |
Titanium alloy wire | Φ(0.1~7.0)ÃL | GR5,GR7,GR9 | ASTM B863 |
Titanium welding wire | Φ(0.8~7.0)ÃL | GR1,GR2,GR3,GR7, GR9,GR12,GR23 | AWS A5.16 |
1.ISO9001:2008
2.Timely delivery rate is 99.8%,sometimes in advance.
3.Excellent after sale service.
4.Rapid enquiry reply,within 2 hours.
5.Fair payment term
6.Proffessional technical adviser
7.Material certificate
8.Quality is strictly according to ASTM,DIN,UNS,GB/T standard(manufacturing process,surface treatment,inspectation and testing).
